Preparing for Installation:

1. It should be checked before unpacking, whether the package is damaged;

and if it is affected with damp

2. Check whether the motor's nameplate data meet the requirements

3. Carefully check the motor, whether it is deformed or damaged during

transport, whether the fasteners are loose or fallen off; try turning the

shaft with hand to see whether the motor is flexible

4. Using a 500V megger to measure the insulation resistance, it should not

be less than 0.5 M？, otherwise the stator windings should be dried, the

drying temperature must not exceed 120 °C

Motor mounting:

1. Good ventilation and cooling conditions should be ensured during

installation of the motor, it should not be used for hot sun and rain

places

2. The motor allows be drived by using couplings, spur gear and pulley, but

for a 2-pol motor above 4kw or a 4-pol motor above 30kw, pulley driving

should better be avoided

3. For vertical mounted motors, other axial load devices are not allowed

except for belt pulley(or equivalent ordinary pulley load)

4. When using a belt drive, the motor shaft and load shaft centerline

parallel surface requires the belt centerline should be vertical to the shaft
